Description
| Hardware | ||
| Main Chipset | MT7620A+7612E | |
| RAM | DDR2 128MB (Max 256MB) | |
| FLASH | 16MB (Max 32MB) | |
|
Antenna |
7 external 5dbi OMNI antennas
(4 for Wi-Fi antennas, 2 for 3/4g module antenna, 1 for GPS antenna, the details need according to customer’s requirements) |
|
| Interface | 1* 10/100M Auto MDI/MDIX LAN | |
| Button | Reset | |
| LED | Power,WLAN,LAN,3G/4G,USB,5G | |
| Power | Input 12V 1A(9-28V) | |
| Consumption | ≦15W | |
| Product Size | 125.5*100.5*25mm | |
| Wireless | ||
|
Protocol Standard |
IEEE 802.11n,
IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.11ac |
|
| Wireless Rate | 2.4GHz: Up to 300Mbps
5.8GHz: Up to 900Mbps |
|
| Work Frequency | 2.4G:2412 MHz-2484MHz(channel 1 -channel 14).
5.8G: 5725MHZ-5850M(channel:149, 153, 157, 161, 165) |
|
| RF Output Power | 802.11b 18dBm±2dBm
802.11g 15dBm±2dBm 802.11n 15dBm±2dBmu 802.11a 20dBm±2dBm 802.11ac 20dBm±2dBm |
|
| Others | ||
|
Work Environments |
Operating Temperature: -20℃ ~ 70℃ Storage Temperature: -40℃~ 70℃Operating Humidity: 10%~90% non-condensing Storage Humidity: 10%~90% non-condensing |
|
LTE 4G module is not included it – please order LTE 4G module based on yoru need. It can support Quectel LTE cat4 and cat 6 4G modules like EC25 and EP06.
